AD8197B,pdf,datasheet下载 4:1 HDMI/DVI Switch with Equalization -The AD8197B is a
The AD8197B is an HDMI鈩?DVI switch featuring equalized TMDS庐 inputs and pre-emphasized TMDS outputs, ideal for systems with long cable runs. The AD8197B offers individual control of the on/off state of the TMDS input termination resistors via I2C control. Outputs can be set to a high impedance state to reduce the power dissipation and/or to allow the construction of larger arrays using the wire-OR technique.
The AD8197B is provided in a 100-lead LQFP, Pb-free, surface-mount package, specified to operate over the 鈭?0掳C to +85掳C temperature range.
